MAX8804Y/MAX8804Z
High-Voltage, Dual-Input, USB/AC
Adapter Chargers in 2mm x 3mm TDFN
Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are
implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.
Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600 ____________________ 15
© 2007 Maxim Integrated Products
is a registered trademark of Maxim Integrated Products, Inc.
Heaney
Package Information (continued)
(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information,
go to www.maxim-ic.com/packages.)
SYMBOL
DIMENSIONS
3.00
2.95
0.75
NOM.
0.70
MIN.
0.20 REF.
0.40
0.02
2.00
0.30
0.00
1.95
E
A
L
A1
D
A2
k
0.20 MIN.
PACKAGE OUTLINE
21-0174
2
2
B
8L TDFN, EXPOSED PAD, 2x3x0.8mm
8
N
3.05
0.80
MAX.
0.50
0.05
2.05
0.50 BSC
e
b
0.25
0.18
0.30
1.60
MIN.
1.75
NOM.
1.90
MAX.
E2
1.50
MIN.
1.63
NOM.
1.75
MAX.
D2
T823-1
PKG.
CODE
EXPOSED PAD PACKAGE
