MAX6615/MAX6616

Dual-Channel Temperature Monitors and
Fan-Speed Controllers with Thermistor Inputs

14

______________________________________________________________________________________

Table 3. Register Map (continued)

R/

W ADD

POR

STATE

FUNCTION

D7

D6

D5

D4

D3

D2

D1

D0

R/

W

1Ch

0000
0000

Fan status

byte

1 = fan 1

failure

1 = fan 2

failure

1 =

disabled

fan 1

tach

1 =

disabled

fan 2 tach

1 =

measure

fan 1

when it is

full speed

1 =

measure

fan 2

when it is

full speed

1 = m ask

FAN_FAIL

p i n

1 = fan 1

fail sets

fan 2

100%

R

1Eh

0000
0000

Channel 1

temp LSBs

MSB

(1/2°C)

LSB

(1/8°C)

R

1Fh

0000
0000

Channel 2

temp LSBs

MSB

(1/2°C)

LSB

(1/8°C)

R

FDh

0000
0001

Read device

revision

0

0

0

0

0

0

0

1

R

FEh

0110
1000

Read device

ID

0

1

1

0

1

0

0

0

R

FFh

0100
1101

Read

m anufactur er

ID

0

1

0

0

1

1

0

1

*GPIO0 POR values are set by PRESET.

Table 4. Configuration Byte Definition (02h)

BIT

NAME

POR

STATE

FUNCTION

7

RUN/STANDBY

0

Set to zero for normal operation. Set to 1 to suspend conversions and PWM outputs.

6

POR

0

Set to 1 to perform reset of all device registers.

5

TIMEOUT

0

Set TIMEOUT to zero to enable SMBus timeout for prevention of bus lockup. Set to 1 to
disable this function.

4

FAN1 PWM INVERT

1

Set fan PWM invert to zero to force PWM1 low when the duty cycle is 100%. Set to 1 to
force PWM1 high when the duty cycle is 100%.

3

FAN2 PWM INVERT

1

Set fan PWM invert to zero to force PWM2 low when the duty cycle is 100%. Set to 1 to
force PWM2 high when the duty cycle is 100%.

2

MIN DUTY CYCLE

0

Set min duty cycle to zero for a 0% duty cycle when the measured temperature is below the
fan-temperature threshold in automatic mode. When the temperature equals the fan-
temperature threshold, the duty cycle is the value in the fan-start duty-cycle register, and it
increases with increasing temperature.
Set min duty cycle to 1 to force the PWM duty cycle to the value in the fan-start duty-cycle
register when the measured temperature is below the fan-temperature threshold. As the
temperature increases above the temperature threshold, the duty cycle increases as
programmed.

1

TEMPERATURE

SOURCE SELECT

0

Selects either local or remote 2 as the source for temperature channel 2 register data.
When D1 = 0, the MAX6615/MAX6616 measure remote 2 and when D1 = 1, the
MAX6615/MAX6616 measure the internal die temperature.

0

SPIN-UP DISABLE

0

Set spin-up disable to 1 to disable spin-up. Set to zero for normal fan spin-up.
