MAX9703/MAX9704
15W, Filterless, Spread-Spectrum
Mono/Stereo Class D Amplifiers
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
(All voltages referenced to GND.)
V
DD
to PGND, AGND .............................................................30V
OUTR_, OUTL_, C1N..................................-0.3V to (V
DD
+ 0.3V)
C1P............................................(V
DD
- 0.3V) to (CHOLD + 0.3V)
CHOLD ........................................................(V
DD
- 0.3V) to +40V
All Other Pins to GND.............................................-0.3V to +12V
Duration of OUTR_/OUTL_
Short Circuit to GND, V
DD
..................................................10s
Continuous Input Current (V
DD
, PGND) ...............................1.6A
Continuous Input Current......................................................0.8A
Continuous Input Current (all other pins)..........................±20mA
Continuous Power Dissipation (T
A
= +70°C)
MAX9703 32-Pin TQFN (derate 21.3mW/°C
above +70°C)..........................................................1702.1mW
MAX9704 32-Pin TQFN (derate 33.3mW/°C
above +70°C)..........................................................2666.7mW
Junction Temperature ......................................................+150°C
Operating Temperature Range ...........................-40°C to +85°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
ELECTRICAL CHARACTERISTICS
(V
DD
= 15V, GND = PGND = 0V,
SHDN ≥ V
IH
, A
V
= 16dB, C
SS
= C
IN
= C
REG
= 0.47µF, C1 = 100nF, C2 = 1µF, FS1 = FS2 = GND
(f
S
= 660kHz), R
L
connected between OUTL+ and OUTL- and OUTR+ and OUTR-, T
A
= T
MIN
to T
MAX
, unless otherwise noted.
Typical values are at T
A
= +25°C.) (Notes 1, 2)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
GENERAL
Supply Voltage Range
V
DD
Inferred from PSRR test
10
25
V
MAX9703
14
22
Quiescent Current
I
DD
R
L
= OPEN
MAX9704
24
34
mA
Shutdown Current
I
SHDN
0.2
1.5
µA
C
SS
= 470nF
100
Turn-On Time
t
ON
C
SS
= 180nF
50
ms
Amplifier Output Resistance in
Shutdown
SHDN = GND
150
330
k
Ω
A
V
= 13dB
35
58
80
A
V
= 16dB
30
48
65
A
V
= 19.1dB
23
39
55
Input Impedance
R
IN
A
V
= 29.6dB
10
15
22
k
Ω
G1 = L, G2 = L
29.4
29.6
29.8
G1 = L, G2 = H
18.9
19.1
19.3
G1 = H, G2 = L
12.8
13
13.2
Voltage Gain
A
V
G1 = H, G2 = H
15.9
16
16.3
dB
Gain Matching
Between channels (MAX9704)
0.5
%
Output Offset Voltage
V
OS
±
6
±
30
mV
Common-Mode Rejection Ratio
CMRR
f
IN
= 1kHz, input referred
60
dB
V
DD
= 10V to 25V
54
80
f
RIPPLE
= 1kHz
80
Power-Supply Rejection Ratio
(Note 3)
PSRR
200mV
P-P
ripple
f
RIPPLE
= 20kHz
66
dB
R
L
= 4
Ω
7.5
Output Power
P
OUT
TH D + N = 10%,
f = 1kH z,
T
A
= + 25° C
R
L
= 8
Ω
, V
DD
= 20V
20
W
