MAX4240–MAX4244
Single/Dual/Quad, +1.8V/10µA, SOT23,
Beyond-the-Rails Op Amps
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS — T
A
= +25°C
(V
CC
= +1.8V to +5.5V, V
EE
= 0, V
CM
= 0, V
OUT
= V
CC
/ 2, R
L
= 100k
Ω
tied to V
CC
/ 2,
SHDN = V
CC
, T
A
= +25°C, unless
otherwise noted.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Supply Voltage (V
CC
to V
EE
) ....................................................6V
All Other Pins ...................................(V
CC
+ 0.3V) to (V
EE
- 0.3V)
Output Short-Circuit Duration (to V
CC
or V
EE
)............Continuous
Continuous Power Dissipation (T
A
= +70°C)
5-pin SOT23 (derate 7.1mW/°C above +70°C).............571mW
8-pin µMAX (derate 4.1mW/°C above +70°C) ..............330mW
8-pin SO (derate 5.88mW/°C above +70°C).................471mW
10-pin µMAX (derate 5.6mW/°C above +70°C) ............444mW
14-pin SO (derate 8.33mW/°C above +70°C)...............667mW
Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +160°C
Lead Temperature (soldering, 10sec) .............................+300°C
PARAMETER
SYMBOL
MIN
TYP
MAX
UNITS
Input Bias Current
I
B
±2
±6
nA
CONDITIONS
Input Offset Voltage
V
OS
±0.20
±0.75
mV
MAX4241ESA
(V
EE
- 0.2V)
≤
V
CM
≤
(V
CC
+ 0.2V)
±0.25
±1.40
MAX4240EUK/MAX424_EUA/
MAX4243EUB
±0.20
±0.88
MAX4242ESA/MAX4243ESD/
MAX4244ESD
Supply Current
per Amplifier
I
CC
10
12
µA
V
CC
= 1.8V
SHDN = V
CC
14
18
V
CC
= 5.0V
2.0
3.0
V
CC
= 5.0V
Shutdown Supply
Current (Note 2)
I
CC(SHDN)
1.0
1.5
µA
V
CC
= 1.8V
SHDN = V
EE
Supply-Voltage Range
V
CC
1.8
5.5
V
Inferred from PSRR test
(Note 3)
(Note 3)
Input Offset Current
I
OS
±0.5
±1.5
nA
V
IN+
- V
IN-
< 1.0V
Differential Input
Resistance
R
IN(DIFF)
45
M
Ω
V
IN+
- V
IN-
> 2.5V
4.4
k
Ω
Inferred from the CMRR test
Input Common-Mode
Voltage Range
V
CM
V
EE
- 0.2
V
CC
+ 0.2
V
V
CC
= 1.8V
Common-Mode
Rejection Ratio
(Note 4)
CMRR
72
90
dB
MAX4241ESA
72
90
MAX4242ESA/MAX4243ESD/
MAX4244ESD
66
88
MAX4240EUK/MAX424_EUA/
MAX4243EUB
V
CC
= 5.0V
77
94
MAX4241ESA
77
94
MAX4242ESA/MAX4243ESD/
MAX4244ESD
72
90
MAX4240EUK/MAX424_EUA/
MAX4243EUB
