Table 1. suggested inductors – Rainbow Electronics MAX8562 User Manual
Page 9

MAX8560/MAX8561/MAX8562
4MHz, 500mA Synchronous Step-Down
DC-DC Converters in SOT and TDFN
_______________________________________________________________________________________
9
MANUFACTURER
SERIES
INDUCTANCE
(µH)
ESR
(
Ω)
CURRENT RATING
(mA)
DIMENSIONS
LB2012
1.0
2.2
0.15
0.23
300
240
2.0 x 1.25 x 1.45 = 3.6mm
3
LB2016
1.0
1.5
2.2
3.3
0.09
0.11
0.13
0.20
455
350
315
280
2.0 x 1.6 x 1.8 = 5.8mm
3
LB2518
1.0
1.5
2.2
3.3
0.06
0.07
0.09
0.11
500
400
340
270
2.5 x 1.8 x 2.0 = 9mm
3
Taiyo Yuden
LBC2518
1.0
1.5
2.2
3.3
4.7
0.08
0.11
0.13
0.16
0.20
775
660
600
500
430
2.5 x 1.8 x 2.0 = 9mm
3
LQH31C_03
1.0
0.28
510
3.2 x 1.6 x 2.0 = 10mm
3
LQH32C_53
1.0
2.2
4.7
0.06
0.10
0.15
1000
790
650
3.2 x 2.5 x 1.7 = 14mm
3
Murata
LQM43FN
2.2
4.7
0.10
0.17
400
300
4.5 x 3.2 x 0.9 = 13mm
3
D310F
1.5
2.2
3.3
0.13
0.17
0.19
1230
1080
1010
3.6 x 3.6 x 1.0 = 13mm
3
TOKO
D312C
1.5
2.2
2.7
3.3
0.10
0.12
0.15
0.17
1290
1140
980
900
3.6 x 3.6 x 1.2 = 16mm
3
Sumida
CDRH2D11
1.5
2.2
3.3
4.7
0.05
0.08
0.10
0.14
900
780
600
500
3.2 x 3.2 x 1.2 = 12mm
3
Table 1. Suggested Inductors
