MAX9030/MAX9031/MAX9032/MAX9034
Low-Cost, Ultra-Small, Single/Dual/Quad
Single-Supply Comparators
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
DD
= +5V, V
SS
= 0, V
CM
= 0, V
SHDN
= +5V (Note 1), T
A
= -40°C to +125°C, unless otherwise noted. Typical values are at
T
A
= +25°C.) (Note 2)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Supply Voltage (V
DD
to V
SS
) ....................................-0.3V to +6V
Voltage Inputs (IN+, IN- to V
SS
). ................-0.3V to (V
DD
+ 0.3V)
Differential Input Voltage (IN+ to IN-) .................................+6.6V
Output Short-Circuit
Duration ...............................................2s to Either V
DD
or V
SS
Current into Any Pin ............................................................20mA
Continuous Power Dissipation (T
A
= +70°C) ...............................
5-Pin SC70 (derate 3.1mW/°C above +70°C) ...............247mW
5-Pin SOT23 (derate 7.1mW/°C above +70°C).............571mW
6-Pin SC70 (derate 3.1mW/°C above +70°C) ...............245mW
6-Pin SOT23 (derate 8.7mW/°C above +70°C).............696mW
8-Pin SOT23 (derate 9.1mW/°C above +70°C).............727mW
8-Pin µMAX (derate 4.5mW/°C above +70°C) ..............362mW
8-Pin SO (derate 5.88mW/°C above +70°C).................471mW
14-Pin TSSOP (derate 9.1mW/°C above +70°C) ..........727mW
14-Pin SO (derate 8.33mW/°C above +70°C)...............667mW
Operating Temperature Range
Automotive Application...................................-40°C to +125°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) ................................ +300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Operating Voltage Range
V
DD
Guaranteed by PSRR test
2.5
5.5
V
S upp l y C ur rent p er C om par ator I
DD
35
55
µA
Supply Current in Shutdown
V
S HDN
= 0 (Note 1)
0.05
1
µA
Shutdown Input Bias Current
V
S HDN
= 0 to V
DD
(Note 1)
0.1
2.5
µA
Shutdown Logic High
(Note 1)
0.7
× V
D D
V
Shutdown Logic Low
(Note 1)
0.3
× V
D D
V
Input Offset Voltage
V
OS
(Note 3)
±1
±5
mV
Input Offset Voltage
Temperature Coefficient
TCV
OS
±1
µV/
°C
Hysteresis
(Note 4)
4
mV
Input Bias Current
I
BIAS
8
80
nA
Input Offset Current
I
OS
±2
±60
nA
Common-Mode Voltage Range
V
CM
Guaranteed by CMRR test
V
SS
V
DD
- 1.1
V
C om m on- M od e Rej ecti on Rati o
CMRR
V
S S
≤ V
C M
≤ ( V
D D
- 1.1V ) , V
D D
= + 5.5V 72
100
d
B
Power-Supply Rejection Ratio
PSRR
V
DD
= +2.5V to +5.5V
72
100
dB
