1. Setting Up the QIL-A9260
1.1. Electrostatic Warning
The QIL-A9260 board is shipped in protective anti-static packaging. The board must not be
subjected to high electrostatic potentials. A grounding strap or similar protective device
should be worn when handling the board. Avoid touching the component pins or any other
metallic element.
1.2. Requirements
In order to use the QIL-A9260 module, the following items are needed:
●
The QIL-A9260 module itself.
●
A QIL motherboard (MB-QIL-A9260 or your own motherboard)
●
AC/DC power adapter (5V at 2A), 2.1 mm by 5.5 mm (MB-QIL-A9260 power supply)
1.3. Layout
Datasheet USG-00006-A01
5/20
