Bank Start address Size Description
Internal memories 0x00000000 256Mbytes
EBI CS0 0x10000000 256Mbytes Available on MB
EBI CS1 (SDRAMC) 0x20000000 64Mbytes Soldered SDRAM
EBI CS2 0x30000000 Not available
EBI CS3 (NAND) 0x40000000 256Mbytes Soldered NAND Flash
EBI CS4 0x50000000 256Mbytes Available on MB
EBI CS5 0x60000000 Not available
EBI CS6 0x70000000 256Mbytes Available on MB
EBI CS7 0x80000000 256Mbytes Available on MB
1.3. Clock Circuitry

12Mhz standard oscillator

32768Hz crystal.
1.4. Reset Circuitry

Internal reset controller with bi-directional reset pin

External reset pushbutton
1.5. Power Circuitry

On board +1.8V low dropout linear regulator
1.6. User Interface

1x user pushbutton

1x user led
1.7. Ethernet

1x DP 83848C PHY
1.8. Expansion slot

1x expansion connector.
The 50 pins expansion connector allows the developer to extend the features of the board by
adding a customized daughter board.
Datasheet USG-00006-A01 11/20
