High-Efficiency, 3A, Current-Mode

Synchronous, Step-Down Switching Regulator

MAX15058

_______________________________________________________________________________________ 3

ELECTRICAL CHARACTERISTICS (continued)

(V

IN

= 5V, T

A

= -40NC to +85NC, unless otherwise noted. Typical values are at T

A

= +25NC.) (Note 3)

Note 3: Specifications are 100% production tested at T

A

= +25NC. Limits over the operating temperature range are guaranteed by

design and characterization.

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

LX Leakage Current

V

EN

= 0V

10

F

A

RMS LX Output current

3

A

OSCILLATOR
Switching Frequency

f

SW

850

1000

1150

kHz

Maximum Duty Cycle

D

MAX

94

%

Minimum Controllable On-Time

70

ns

Slope Compensation Ramp
Valley

1.15

V

Slope Compensation Ramp
Amplitude

V

SLOPE

Extrapolated to 100% duty cycle

320

mV

ENABLE
EN Input High Threshold Voltage

V

EN

rising

1.45

V

EN Input Low Threshold Voltage

V

EN

falling

0.4

V

EN Input Leakage Current

V

EN

= 5V

0.025

F

A

SKIP Input Leakage Current

V

SKIP

= V

EN

= 5V

25

F

A

SOFT-START, PREBIAS, REFIN
Soft-Start Current

I

SS

V

SS/REFIN

= 0.45V, sourcing

10

F

A

SS/REFIN Discharge Resistance

R

SS

I

SS/REFIN

= 10mA, sinking

8.3

I

SS/REFIN Prebias Mode Stop
Voltage

V

SS/REFIN

rising

0.58

V

External Reference Input Range

0

IN - 1.8

V

HICCUP
Number of Consecutive Current-
Limit Events to Hiccup

8

Events

Timeout

1024

Clock

Cycles

POWER-GOOD OUTPUT
PGOOD Threshold

V

FB

rising

0.535

0.555

0.575

V

PGOOD Threshold Hysteresis

V

FB

falling

28

mV

PGOOD V

OL

I

PGOOD

= 5mA, V

FB

= 0.5V

20

60

mV

PGOOD Leakage

V

PGOOD

= 5V, V

FB

= 0.65V

0.013

F

A

THERMAL SHUTDOWN
Thermal Shutdown Threshold

150

N

C

Thermal Shutdown Hysteresis

Temperature falling

20

N

C
