MAX9550/MAX9551/MAX9552
High-Current VCOM Drive Buffers
for TFT LCDs
8
_______________________________________________________________________________________
GND
IN-
IN+
1
5
V
DD
OUT
MAX9550
MAX9550
THIN SOT23
TOP VIEW
2
3
4
1
2
3
4
8
7
6
5
N.C.
V
DD
OUT
N.C.
GND
IN+
IN-
N.C.
µMAX-EP
MAX9551
MAX9552
1
2
3
4
8
7
6
5
V
DD
OUTB
INB-
INB+
GND
INA+
INA-
OUTA
µMAX-EP
14
13
12
11
10
9
8
1
2
3
4
5
6
7
OUTD
IND-
IND+
GND
V
DD
INA+
INA-
OUTA
INC+
INC-
OUTC
OUTB
INB-
INB+
TSSOP-EP
Pin Configurations
Chip Information
PROCESS: BiCMOS
