MAX66100
ISO 15693-Compliant 64-Bit UID
_______________________________________________________________________________________ 5
Figure 8. Downlink SOF for “1 Out of 256” Coding (Carrier Not Shown)
~ 9.44 μs
~ 37.76 μs ~ 37.76 μs
~ 9.44 μs
Figure 7. Downlink Data Coding (Case “1 Out of 4”) (Carrier Not Shown)
PULSE POSITION “00”
PULSE POSITION “01” (1 = LSb)
PULSE POSITION “10” (0 = LSb)
PULSE POSITION “11”
~ 9.44 μs ~ 9.44 μs
~ 9.44 μs
~ 9.44 μs
~ 9.44 μs
~ 75.52 μs
~ 75.52 μs
~ 75.52 μs
~ 75.52 μs
~ 66.08 μs
~ 28.32 μs
~ 47.20 μs
