TABLE I ADC10738 Multiplexer Address Assignment
MUX Address Channel Number
MODE
MUX MA0 MA1 MA2 MA3 MA4
CH0 CH1 CH2 CH3 CH4 CH5 CH6 CH7 COM
PU
SING ODD
SEL1 SEL0
DIFF SIGN
1 1 0 0 0 a b
1 1 0 0 1 a b
1 1 0 1 0 a b
1 1 0 1 1 a b
Single-Ended
1 1 1 0 0 a b
1 1 1 0 1 a b
1 1 1 1 0 a b
1 1 1 1 1 a b
1 0 0 0 0 a b
1 0 0 0 1 a b
1 0 0 1 0 a b
1 0 0 1 1 a b
Differential
1 0 1 0 0 b a
1 0 1 0 1 b a
1 0 1 1 0 b a
1 0 1 1 1 b a
0 X X X X Power Down (All Channels Disconnected)
TABLE II ADC10734 Multiplexer Address Assignment
MUX Address Channel Number
MODE
MUX MA0 MA1 MA2 MA3 MA4
CH0 CH1 CH2 CH3 COM
PU
SING ODD
SEL1 SEL0
DIFF SIGN
1 1 0 0 0 a b
1 1 0 0 1 a b
Single-Ended
1 1 1 0 0 a b
1 1 1 0 1 a b
1 0 0 0 0 a b
1 0 0 0 1 a b
Differential
1 0 1 0 0 b a
1 0 1 0 1 b a
0 X X X X Power Down (All Channels Disconnected)
TABLE III ADC10732 Multiplexer Address Assignment
MUX Address Channel Number
MODE
MUX MA0 MA1 MA2 MA3 MA4
CH0 CH1 COM
PU
SlNG ODD
SEL1 SEL0
DIFF SIGN
1 1 0 0 0 a b
Single-Ended
1 1 1 0 0 a b
1 0 0 0 0 a b
Differential
1 0 1 0 0 b a
0 X X X X Power Down (All Channels Disconnected)
