MAX4074–MAX4078
Micropower, SOT23, Rail-to-Rail,
Fixed-Gain, GainAmp/Open-Loop Op Amps
_______________________________________________________________________________________ 7
10 µs/div
INPUT
OUTPUT
50mV/div
A V = +1.25V/V
OUTPUT
50mV/div
A V = +3V/V
OUTPUT
50mV/div
A V = +5V/V
OUTPUT
50mV/div
A
V
= +10V/V
OUTPUT
50mV/div
A V = +25V/V
OUTPUT
50mV/div
A V = +51V/V
SMALL-SIGNAL PULSE RESPONSE
MAX4074 TOC36
Typical Operating Characteristics (continued)
(V CC = +5.0V, R L = 100k Ω to V
CC /2, T A = +25°C, unless otherwise noted.)
10 µs/div
INPUT
OUTPUT
500mV/div
A V = +1.25V/V
OUTPUT
500mV/div
A V = +3V/V
OUTPUT
500mV/div
A V = +5V/V
OUTPUT
500mV/div
A V = +10V/V
OUTPUT
500mV/div
A V = +25V/V
OUTPUT
500mV/div
A V = +51V/V
LARGE-SIGNAL PULSE RESPONSE
MAX4074 TOC35
MAX4074/MAX4075
