MAX5360/MAX5361/MAX5362
Low-Cost, Low-Power 6-Bit DACs with
2-Wire Serial Interface in SOT23 Package
4 _______________________________________________________________________________________
TIMING CHARACTERISTICS (continued)
(V DD = 2.7V to 3.6V (MAX5360); V DD = 4.5V to 5.5V (MAX5361); V DD = 2.7V to 5.5V (MAX5362); R L =10k Ω, C
L = 50pF, T A = T MAX to
T MIN , Figure 3, unless otherwise noted. Typical values are T A = +25°C.)
Data Hold Time t HD, DAT 0 0.9 µs
Data Setup Time t SU, DAT 100 ns
Rise Time of Both SDA and
SCL Signals
t
r
300 ns
Fall Time of Both SDA and
SCL Signals
t
f
CONDITIONS
300 ns
Setup Time for STOP Condition t SU, STO 0.6 µs
Capacitive Load for Each
Bus Line
C b 400 pF
µs 0.6 t SU, STA
Setup Time for a Repeated
START Condition
UNITS MIN TYP MAX SYMBOL PARAMETER
Note 1: Guaranteed from code 1 to code 63.
Note 2: The offset value extrapolated from the range over which the INL is guaranteed.
Note 3: MAX5362, tested at V
DD
= 5V ±10%.
Note 4: MAX5360, tested at V DD = 3V ±10%; MAX5361, tested at V DD = 5V ±10%.
Note 5: Actual output voltage at full scale is 63/64 ✕ V REF .
Note 6: Output settling time is measured by taking the code from code 1 to code 63, and from code 63 to code 1.
Note 7: Guaranteed by design.
-0.045
-0.020
-0.030
-0.025
-0.035
-0.040
-0.015
-0.010
-0.005
0
0.005
0.010
0.015
0.020
0.025
0.030
0 25 50 75
INTEGRAL NONLINEARITY vs. CODE
MAX5360/1/2-01
CODE
INL (LSB)
0
-0.025
-0.050
2.5 4.0 3.0 3.5 4.5 5.0 5.5
INTEGRAL NONLINEARITY
vs. SUPPLY VOLTAGE
MAX5360/1/2-02
SUPPLY VOLTAGE (V)
INL (LSB)
0
-0.025
-0.050
-40 20 -20 0 40 60 80 100
INTEGRAL NONLINEARITY
vs. TEMPERATURE
MAX5360/1/2-03
TEMPERATURE ( °C)
INL (LSB)
Typical Operating Characteristics
(V DD = 3V (MAX5360), V DD = 5V (MAX5361/MAX5362), T A = +25°C, unless otherwise noted.)
