21
General
Dimensions (W x H x D):
Weight:
Finish:
Signal in Meter
(all digital inputs):
Stereo PPM Bridge
(Stereo, MONO, SIDE):
Mains Power Supply:
Power Consumption:
Warranty Parts and labor:
5.5" x 2.5" x 6.9" (140 x 64 x 176 mm)
1.8 lb. (0.82 kg)
Acrylic and anodized aluminum front panel.
Plated and coated chassis. Rubber coated
side plates.
1 LED per stereo channel
(activated at -60 dBFs)
12 LEDs per channel
12 VDC
< 8.4 W
1 Year
DAC
D to A Conversion:
D to A Delay:
Headphones Output
Connectors
Impedance
Max. Output Level:
Digital gain:
THD:
Dynamic Range:
Freq. Response:
Power @ 40 Ohm Load:
Power @ 600 Ohm Load:
EMC
Complies with:
Safety
Certified to:
Environment
Operating Temperature:
Storage Temperature:
Humidity:
24 bit, 128 x Oversampling Bitstream
0.40 ms / 0.20 ms @ 48 kHz / 96 kHz
1/4" Phone Jack (Stereo)
80 Ohm
+20 dBu (no load)
Off to +12 dB
< -85 dB (0.006 %) @ 1 kHz,
-1 dBFS, 0 dB gain, 300 Ohm
> 102 dB, 20 Hz to 20 kHz
+0/-0.2 dB, 20 Hz to 20 kHz
200 mW
93 mW
EN 55103-1 and EN 55103-2,
FCC part 15 Class B, CISPR 22 Class B
IEC 60065, EN 60065, UL60065 and
CSA E60065 CSA FILE #LR108093
32° F to 122° F (0° C to 50° C)
-22° F to 167° F (-30° C to 70° C)
Max. 90 % non-condensing
TECHNICAL SPECIFICATIONS
Due to continuous development,
these specifications are subject to change
without notice.
