Functional Block Diagram
The 9032-SD has a very flexible signal flow path and feature set that combines several products into
one compact package. This section diagrams the basic signal flow of your 9032-SD product.
Figure 1. Simplified Block Diagram of 9032-SD Functions
Supported Audio and Video Formats
Input and Output Video
The 9032-SD supports the following video formats.
Raster structure Frame Rate
486i
1
29.97
575i
1
25
Notes:
1. All rates displayed as frame rates, interlaced (“i”) field rates are two times the number shown.
Documentation Terms
The following terms are used throughout this guide:
•
“Frame” refers to the HPF-9000 or 8321 frame that houses the 9032-SD card.
•
“Operator” and “User” both refer to the person who uses the 9032-SD.
•
“Board” and “Card” all refer to the 9032-SD card itself, including all components
and switches.
•
“System” and “Video system” refers to the mix of interconnected production and
terminal equipment in which the 9032-SD operates.
SD SDI
Output
9032-SD Block Diagram
Analog to Digital
Conversion
Video Proc:
Gain, Lift, Saturation, Phase
Serializer
and Cable
Driver
Frame
Sync
SD Analog
Input
