Page 14 9032-SD Owner’s Manual •••• (V 2.1)
Vertical Offset
Allows the user to specify an additional vertical offset between the output video and the frame sync
reference in lines. These are lines in the reference format, not the output video format.
Frame Latency
Specifies the smallest amount of latency allowed by the frame sync. This latency measurement is in
frames of the output video. The frame sync will not output a frame unless the specified number of
frames are captured in the buffer. Minimum latency is three lines and zero frames in all video modes.
The maximum latency is format dependent. The operational latency of the frame sync is always
between the specified minimum latency and minimum latency plus one frame (not one field).
Audio Delay
Specifies the amount of additional audio delay after matching video delay. When the change is under
one and a half frames, the change in audio delay will be applied without interrupting audio. When
changing audio delay more than a frame and a half at a time, there will be a slight audio glitch.
Video Delay
Reports the current amount of video delay in ms.
Reset Frame Sync
Resets the frame sync, clearing any buffered audio and video. You must reset the framesync after
manipulating the horizontal and vertical offset in order re-establish correct audio and video co-timing.
Display Submenu
Menu Structure Parameter Type
Disp H/V Display Orientation
BRGT Display Brightness
Display Orientation
This parameter lets you change the orientation of the display. “Vert” makes the characters look correct
when the cards are mounted in a 2 RU frame like the 8321 frame. “Horz” makes the characters look
right in a horizontal frame.
Display Brightness
This parameter allows you to set the standard output brightness of the menu display. It is a percentage
of maximum brightness.
Preset Submenu
MENU STRUCTURE Parameter Type
Slct Select Preset
Save Save Settings
Load Load Settings
Prst
Fact Restore Factory Settings
