Page 18 9032-SD Owner’s Manual •••• (V 2.1)
Menu Item Format Description
Card Name
Up to 32 ASCII
Characters Allows the card to be
renamed in the Tree View.
Selected Preset
1-16 Selects a preset to Save or
Load.
Preset Name
Up to 6 ASCII
Characters Specifies a unique name
when saving a preset.
Preset Save Confirm
Saves the parameters as
preset.
Preset Load Confirm
Loads parameters
previously saved.
Presets
Reset Current
Preset
Confirm
Will load factory presets
and overwrite the save.
Menu Item Format Description
Composite
Y/C
YPbPr BetaCam
YPbPr MII
SD Input Type
YPbPr SMPTE
Selects the format of
input SD analog video, so
the decoder can properly
decode the signal.
Video Signal
Controls
SD Composite
Contains
0.0 or 7.5 IRE of Setup
Specifies the amount of
setup (pedestal) in the
input video. It will be
removed by the decoder.
Menu Item Format Description
Video Gain
Range 0-2000 Gain applied to Y (Luma).
1000 is unity.
Video Lift
Range (-999) – 999 Lift applied to Y (Luma),
in 10 bit code value.
Color Gain Range 0-2000
Gain applied to C
(Chroma). 1000 is unity.
Color Phase Range (–360) – 360
Phase of C (Chroma) in
degrees.
Video Proc
Reset to Unity Confirm
Resets all of the proc
controls to unity.
