9392-TCB-OM (V1.3) 9392-TCB PRODUCT MANUAL 1-11
Introduction
Technical Specifications
9392 Rear Modules
The 9392 physically interfaces to system video and audio connections using a
Rear Module.
All inputs and outputs shown in the block diagram (Figure 1-1) enter and exit
the card via the card edge backplane connector. The Rear Module breaks out
the 9392 card edge connections to industry standard connections that
interface with other components and systems in the signal chain.
9392 Rear Modules are shown and described in Chapter 2, “Installation and
Setup”.
Technical Specifications
Table 1-1 lists the technical specifications for the 9392-TCB 3G/HD/SD-SDI
Dual-Channel Timecode Burn-In Inserter card.
Table 1-1 Technical Specifications
Item Characteristic
Part number, nomenclature 9392-TCB 3G/HD/SD-SDI Dual-Channel Timecode Burn-In Inserter
Installation/usage environment Intended for installation and usage in frame meeting openGear®
modular system definition.
Power consumption < 25 Watts
Environmental:
Operating temperature:
Relative humidity (operating or storage): 32° – 104° F (0° – 40° C)
< 95%, non-condensing
Frame communication 10/100 Mbps Ethernet with Auto-MDIX.
Standards supported 3G: SMPTE 425 level A and B
1080p60, 1080p59.94, 1080p50
HD: 1080i60, 1080i59.94, 1080i50, 1080p29.97, 1080p25, 1080p24;
1080p23.98
720p60, 720p59.94, 720p50, 720p29.97, 720p25, 720p24,
720p23.98
SD: 486i59094, 576i50
Internally generated flat-field formats
Note: Flat-field format is user-selectable using GUI
controls and independent of received (input video)
format
3G: 1080p59.94, 1080p50
HD: 1080i59.94, 1080i50, 1080psf23.98
720p59.94, 720p50
SD: 525i59.94, 625i50
