MP-201 Multi-Pedal Manual
Firmware v2.0 Addendum
LFO
LFO WAVEFORM
(TRIANGLE, SQUARE, SAW DOWN, RAMP UP, S+H)
LFO SYNC
(FREE RUNNING, TAP TEMPO, CH1-4, MIDI CLOCK)
LFO RATE
(0 - 4095 or MIDI Clock Divisions)
LFO AMOUNT
(0 - 4095)
LFO OFFSET
(0 - 4095)
FPEDAL MODE
(RATE, AMOUNT, OFFSET)
HEEL VALUE
(0 - 4095)
TOE VALUE
(0 - 4095)
LFO OFF MODE
(INITIAL, CURRENT, CONTINUOUS)
INITIAL VAL
(0 - 4095)
CV LAG
(OFF, ON)
if “ON”:
RISE TIME
(0 - 4095)
FALL TIME
(=RISE TIME, 1 - 4095)
CHAN OUTPUT
(CV AND MIDI, CV ONLY, MIDI ONLY)
MIDI CC #
(OFF, 0 - 127)
MIDI TO CV
ROOT NOTE=0V
(0 - 127)
CV SCALE
(0.667 – 1.333)
PITCH BEND
(OFF, 1-12 Semitones, 24 Semitones)
GLIDE MODE
(OFF, ON, LEGATO ON)
GLIDE RATE
(0 - 4095)
GLIDE TYPE
(CONST.TIME, LOG, EXP, CONST.RATE)
NOISE
NOISE AMOUNT
(0 - 4095)
NOISE OFFSET
(0 - 4095)
FPEDAL MODE
(NOISE AMOUNT, NOISE OFFSET)
HEEL VALUE
(0 - 4095)
TOE VALUE
(0 - 4095)
OFF MODE
(INITIAL, OFFSET VAL, CONTINUOUS)
INITIAL VAL
(0 - 4095)
RESOLUTION
(3 – 12 Bits)
CHAN OUTPUT
(CV AND MIDI, CV ONLY, MIDI ONLY)
MIDI CC #
(OFF, 0 - 127)
Page | 10
Specifications subject to change without notice
