Voyager XL User’s Manual - MIDI
Page 81
Voyager XL User’s Manual - MIDI
SECTION
CONTROL
FUNCTION
CC
VALUE/RANGE
Filter
CUTOFF
Adjusts the filter cutoff frequency
19 MSB, 51 LSB
-
SPACING
Adjusts the filter spacing parameter
20 MSB, 52 LSB
-
RESONANCE
Adjusts the filter resonance parameter
21 MSB, 53 LSB
-
KB AMOUNT
Adjusts the amount of pitch CV affecting the
cutoff
22 MSB, 54 LSB
-
MODE
Toggles the filter mode between LP/LP and
HP/LP
86
0-63 OFF, 64-127 ON
En
velope Gener
ator
FILTER ENV ATTACK
Adjusts the filter envelope attack time
23 MSB, 55 LSB
-
FILTER ENV DECAY
Adjusts the filter envelope decay time
24 MSB, 56 LSB
-
FILTER ENV SUSTAIN
Sets the filter envelope sustain level
25 MSB, 57 LSB
-
FILTER ENV RELEASE
Adjusts the filter envelope release time
26 MSB, 58 LSB
-
AMOUNT TO FILTER
Adjusts the amount of filter envelope affecting
the cutoff
27 MSB, 59 LSB
-
VOLUME ENV ATTACK
Adjusts the volume envelope attack time
28 MSB, 60 LSB
-
VOLUME ENV DECAY
Adjusts the volume envelope decay time
29 MSB, 61 LSB
-
VOL ENV SUSTAIN
Sets the volume envelope sustain level
30 MSB, 62 LSB
-
VOL ENV RELEASE
Adjusts the volume envelope release time
31 MSB, 63 LSB
-
ENV GATE SWITCH
Toggles the envelope gate between Keyboard
and ON/EXT
87
0-63 OFF, 64-127 ON
Vol
MASTER VOLUME
Adjusts the master volume level
7 MSB, 39 LSB
-
Voyager XL MIDI CC data assignments
