32
Series 2000 Vane Axial Heater
HEATER PARTS
Key Part Number Description
1 HH-1077 1/2" regulator
2 HH-3670 1/2" x 2-1/2" nipple
3 TFC-0032 1/2" solenoid
4 HH-2029 1/2" x 1-1/2" nipple
5 HH-2984 1/4" gauge 30PSI
6 S-3853 1/2" x 1/4" x 1/2" tee
7 HH-1083 18/24/28" Orifice pipe
7 HH-1107 26" Orifice pipe
8 HF-7036 5/32" Orifice plug (18" Standard)
8 CD-0149 5/64" Orifice plug (18" lo-temp)
8 HF-7086 3/16" Orifice plug (24" Standard)
8 HF-7084 3/32" Orifice plug (24/26/28" lo-temp)
8 HF-7087 7/32" Orifice plug (26" Standard)
8 HF-7088 15/64" Orifice plug (28" Standard)
9 HH-2653 Modulating valve (optional)
Axial Propane Vapor Pipetrain
