2. Dryer Dimensions, Stiffener and Catwalk Locations
PNEG-1744 H-Series Catwalk Installation 15
Catwalk Support Installation for Locations with No Stiffeners Parts List
Ref # Part # Description Qty
1 D31-0055 Column Bulkhead 1
2 401-4713-4 Catwalk Section 1
3 401-4753-0 Adapter Channel Support 4
4 401-4717-5 Support Angle 2
5 401-4719-1 Brace at Dryer 2
6 S-9067 Flange Bolt 3/8"-16 x 3/4" ZN Grade 5 8
7 S-968 Flange Nut 3/8"-16 ZN Grade 5 8
8 401-4720-9 Filler Plate 1
9 325-2091-8 Channel - Support 1
10 S-7645 Carriage Bolt 5/16"-18 x 3/4" ZN Grade 5 20
11 S-3611 Flange Nut 5/16"-18 ZN YDP 22
12 S-6606 Flange Bolt 5/16"-18 x 3/4" ZN Grade 5 2
