7. Parts List
PNEG-1853 12' Tower Dryer Fan Style Catwalk Assembly
63
12' Outside Fan Style Catwalk (GT4-1039-12F) Parts List
Ref #
Part #
Description
Qty
1
GT1-0001
Vertical Channel
16
2
GT1-2036
Catwalk/Platform to Dryer Wall Bracket
8
3
GT1-2035
Inner Toe Board
7
4
GT1-2033
Plank
45
5
GT1-2034-12
Outer Toe Board
12
6
GT1-2039-BS
Outside/Inside Catwalk Diagonal Support - Bin Silver
8
7
GT1-2040-BS
Catwalk Support Clip - Bin Silver
8
8
GT1-2037-BS
Catwalk Vertical Support - Bin Silver
9
9
GT1-2038-12O
12' Outside Catwalk/Platform Handrail
16
10
GT1-2086
Catwalk Plank Support
1
11
GT4-1465
Ladder Opening Inner Toe Board
1
12
GT1-2087
Swing Gate Support
2
13
GT1-0920
Catwalk End Handrail
4
14
GT4-1455
Ladder Safety Gate
2
15
GT1-2045
Platform End Plate
1
16
GT1-2091
Swing Gate Stop Plate
1
17
GT1-2088
Ladder to Toe Board Bracket
2
18
S-4303
Truss Bolt 5/16"-18 x 3/4" YDP Grade 8 or Grade 8.2
200
19
S-7927
Flange Bolt 3/8"-16 x 1" YDP Grade 8 or Grade 8.2
363
20
S-968
Flange Nut 3/8"-16 ZN Grade 5 Wide Flange
363
21
S-10171
Bolt, U-Bolt 5/16"-18 for 1-1/4" Pipe ZN
20
22
S-3611
Flange Nut 5/16"-18 YDP Grade 2
220
N/S
090-1709-6
Retainer Nut 5/16"-18 x 0.120" ZN
53
N/S
GT1-2144
Holding Plate, Inner Toe Board to Plank
26
N/S
S-10175
Extruded Nut 3/8"-16, Tapped Hole, 050-0.200 Panel Range, Black
52
