Chapter 7: Roof Assembly

Figure 7-42 Conveyor support brackets

A

3/8 x 1-1/2 in. flange bolt, (S-7488)

C

3/8 in. flange nut (S-456)

B

Conveyor support bracket (CTR-0087)

D

Caulk

After You Finish

Repeat this procedure for the remaining conveyor support brackets.

Pneg-4075A 75 Ft Diameter 40-Series Bin

121
