Chapter 7: Roof Assembly
Figure 7-40 Lifting the center collar channel and cap plates
A Tube caulk D Cap plate assembly, approximately 912 lb (413.67
kg)
B Appropriate lifting chains E 1/2 x 1-3/4 in. flange bolt (S-10252)
C Appropriate lifting device F 1/2 in. nut (S-10253)
8. Secure the cap plate assembly to the center collar using bolts with sealing washers (G) and nuts (H),
leaving the peak conveyer support bracket holes (I) unfilled.
9. Replace the four vendor eyebolts with the supplied bolts with sealing washers (G) and nuts (H).
10.Tighten all hardware to the recommended torque specifications. See Bolt Torque Specifications,
page 24 .
Pneg-4075A 75 Ft Diameter 40-Series Bin 119
