Chapter 7: Roof Assembly

NOTE: It is better to set the center collar a little too high. Do not set the center collar too low.

Figure 7-25 Center collar placement

A

280.984 (713.70 cm) in. from foundation to bottom of center collar on 75 ft diameter bin

Pneg-4075A 75 Ft Diameter 40-Series Bin

101
