24
Deluxe Vane Axial Heater HEATER PARTS
24" & 26" Gas Heater
Key Part Number Description
1 HF-6175 24" Heater Housing
1 HF-6176 26" Heater Housing
2 HH-3934 24/26" Burner Casting
3 HH-1179 24/26" Flame Spreader
3 HF-6757 24/26/28" Lo-Temp Flame Spreader
4 HF-7103 24/26" Flame Diverter
4 HF-7107 24/26/28" Lo-Temp Flame Diverter
4 HF-7104 24/26" Diverter Collar
5 HF-6062-24 24" Access Panel (Deluxe, Sr 2000)
5 HF-7381-24 24" Access Panel (Standard)
5 HF-6062-26 26" Access Panel (Deluxe, Sr 2000)
5 HF-7381-26 26" Access Panel (Standard)
6 HF-7380 Plastic View Window
7 HF-7379 Access Panel Cover Plate
8 TFH-2046 Access Panel Latch
9 HF-983 18/24" Burner Collector
9 HF-986 26" Burner Collector
10 HF-978 18/24/26" Burner Collector Plate
11 HH-7016 Rubber Grommet
12 HF-7056 Pivot Bracket
13 HF-7057 Adjustment Bracket
14 HF-7060 Vaporizer Support Weldment
15 THF-3237 Vaporizer Cover
16 HH-1650 Spark Plug
NS HF-1810 Spark Plug Nut
NS HF-7260 18-28" Heater Spark Plug Wire
NS HF-7262 18-28" Heater Flame Probe Wire
17 *THH-4179 Flame Sensor (Deluxe, Sr 2000)
17 HH-1097 Flame Probe (Standard)
18 CD-0187 Flame Sensor Bracket (Deluxe, Sr 2000)
18 HF-4485 Flame Probe Bracket (Standard)
19 HH-7054 24-28" Burner Cone
