6. Layouts
44 PNEG-1834 78' Dura-Lok Plank and Support Manual
78' Dura-Lok Bundle Layout (Continued)
NOTES:
1. Looking from end of the bundle where all plank edges are butted flush.
2. One AB2 bundle required for complete order. Two (2) AB1 bundles, one C1 bundle and
one C2 bundle also needed.
3. Plank banding and sub-banding denoted by grid lines in charts.
C1
Plank Layout by Marking Plank Layout by Length
3B 2A 102 77
3A 2B 1 174 149 160
9C 7C 5C 4A 240 240 240 146-1/2
10C 8C 6C 4B 240 240 240 194-1/2
17C 15C 13C 11C 240 240 240 240
18C 16C 14C 12C 240 240 240 240
25C 23C 21C 19C 240 240 240 240
26C 24C 22C 20C 240 240 240 240
33C 31C 29C 27C 240 240 240 240
34C 32C 30C 28C 240 240 240 240
41C 39C 37C 35C 240 240 240 240
42C 40C 38C 36C 240 240 240 240
49C 47C 45C 43C 240 240 240 240
50C 48C 46C 44C 240 240 240 240
57C 55C 53C 51C 240 240 240 240
58C 56C 54C 52C 240 240 240 240
65C 63C 61C 59C 240 240 240 240
66C 64C 62C 60C 240 240 240 240
C2
Plank Layout by Marking Plank Layout by Length
2B 2A 149 77
3A 1 174 160
8C 6C 4B 3B 240 240 194-1/2 102
9C 7C 5C 4A 240 240 240 146-1/2
16C 14C 12C 10C 240 240 240 240
17C 15C 13C 11C 240 240 240 240
24C 22C 20C 18C 240 240 240 240
25C 23C 21C 19C 240 240 240 240
32C 30C 28C 26C 240 240 240 240
33C 31C 29C 27C 240 240 240 240
40C 38C 36C 34C 240 240 240 240
41C 39C 37C 35C 240 240 240 240
48C 46C 44C 42C 240 240 240 240
49C 47C 45C 43C 240 240 240 240
56C 54C 52C 50C 240 240 240 240
57C 55C 53C 51C 240 240 240 240
64C 62C 60C 58C 240 240 240 240
65C 63C 61C 59C 240 240 240 240
