4. Monorail Installation
18 PNEG-1834 78' Dura-Lok Plank and Support Manual
Monorail “Rail and Leg Spacing”/“Full Floor Leg Quantity” for 78' Bin Diameter
4.00"
Ring
2.66"
Ring
Eave Height (ft.) Rail Spacing
Reference
Page
Leg Spacing Leg Qty
3 4 11 26 See Page 41 22 1589
4 6 16 26 See Page 41 20 1738
5 8 22 22 See Page 38 20 1962
7 10 27 22 See Page 38 19 2060
9 12 33 20 See Page 37 18 2367
10 14 38 20 See Page 37 17 2500
11 16 43 18 See Page 34 18 2370
13 18 48 18 See Page 34 17 2502
14 20 54 18 See Page 34 16 2650
16 22 59 17 See Page 33 16 2880
17 24 64 17 See Page 33 16 2880
19 26 70 16 See Page 30 15 3388
20 28 75 16 See Page 30 15 3388
22 30 81 15 See Page 29 15 3321
23 32 86 15 See Page 29 15 3321
25 34 92 15 See Page 29 15 3321
27 37 100 14 See Page 26 15 3787
