PNEG-256 6', 7' & 9' Bulk Feed Tanks 65
14. PARTS SECTION
6' Diameter 60° Hopper Bin parts list
Note: Bolt listed first and nut second for each usage.
Hardware usage: Heads of Bolts are on the outside of tank unless otherwise noted.
Ref # Part # Qty Description
1 S-275 36 Bulk Tank Peak Ring to Roof Panels (Use 5/16" x 3/4" Hex Head Bin Bolts
and 5/16" Hex Nuts.)
S-396 36
2 S-275 48 Roof Panel to Roof Panel (Use 5/16" x 3/4" Hex Head Bin Bolts and 5/16"
Hex Nuts.)
S-396 48
3 S-275 72 Roof Panels to Top Sidewall Sheets (Use 5/16" x 3/4" Hex Head Bin Bolts
and 5/16" Hex Nuts.)
S-396 72
4 S-275 Varies Vertical Sidewall Sheet Seams (Use 5/16" x 3/4" Hex Head Bin Bolts and
5/16" Hex Nuts.)
S-396 Varies
5 S-275 Varies Horizontal Sidewall Sheet Seams (Use 5/16" x 3/4" Hex Head Bin Bolts
and 5/16" Hex Nuts.)
S-396 Varies
6 S-275 48 Leg to Sidewall Sheet (Use 5/16" x 3/4" Hex Head Bin Bolts and 5/16" Hex
Nuts.) (Bolt Heads to Inside of Tank.)
S-396 48
7 S-277 72 Hopper Panels to Sidewall Sheet (Use 5/16" x 1-1/4" Hex Head Bin Bolts
and 5/16" Hex Nuts.) (Bolt Head to Inside at Leg to Hopper to Sidewall
Connection Only.)
S-396 72
8 S-4303 108 Vertical Hopper Seams (Use 5/16" x 3/4" Truss Head Bin Bolts and 5/16"
Flanged Whiz Nuts.) (Bolt Heads to Inside of Tank.)
S-3611 108
9 S-4303 24 or
36
Hopper Collar to Hopper Panel (Use 5/16" x 3/4" Truss Head Bin Bolts and
5/16" Flanged Whiz Nuts.) (Bolt Heads to Inside of Tank.) (16" Shown)
S-3611 24 or
36
10 S-7927 4 Hopper Brace to Leg (Use 3/8" x 1" Flange Head Bolts and 3/8" Hex Nuts.)
S-456 4
