Pressure chart, Static pressure chart for rice (w/ stirring) – Grain Systems PNEG-501 User Manual
Page 16
16
Fan/Heater Application
PRESSURE CHART
STATIC PRESSURE CHART FOR RICE (W/ STIRRING)
3
2
1
3/4
1/2
1/3
1/4
1/5
1/7
1/10
1/15
1/20
2
0.64
0.59
0.54
0.53
0.52
0.51
0.51
0.51
0.51
4
1.14
0.89
0.68
0.63
0.58
0.56
0.54
0.53
0.52
0.52
0.51
0.51
6
2.09
1.45
0.92
0.80
0.70
0.63
0.59
0.57
0.55
0.54
0.52
0.52
8
3.59
2.32
1.28
1.06
0.86
0.73
0.67
0.63
0.59
0.57
0.54
0.53
10
5.72
3.53
1.77
1.41
1.07
0.86
0.77
0.71
0.65
0.60
0.57
0.55
12
8.57
5.13
2.41
1.85
1.34
1.03
0.89
0.81
0.72
0.65
0.60
0.57
14
12.22
7.15
3.19
2.39
1.67
1.24
1.04
0.92
0.80
0.70
0.63
0.60
16
16.73
9.63
4.14
3.04
2.06
1.48
1.21
1.06
0.89
0.77
0.68
0.63
18
12.61
5.26
3.81
2.52
1.76
1.41
1.21
1.00
0.84
0.72
0.67
20
16.11
6.56
4.69
3.05
2.08
1.64
1.39
1.12
0.92
0.78
0.71
22
20.18
8.06
5.70
3.64
2.44
1.90
1.59
1.25
1.01
0.84
0.75
24
9.76
6.85
4.31
2.84
2.18
1.81
1.40
1.12
0.90
0.80
26
11.67
8.13
5.06
3.29
2.50
2.05
1.57
1.23
0.97
0.85
28
13.80
9.55
5.88
3.78
2.84
2.31
1.75
1.35
1.05
0.91
30
16.16
11.12
6.79
4.31
3.22
2.60
1.94
1.48
1.13
0.97
32
18.76
12.85
7.78
4.90
3.63
2.91
2.15
1.62
1.22
1.04
34
14.73
8.86
5.53
4.07
3.25
2.38
1.77
1.32
1.11
36
16.78
10.02
6.21
4.54
3.61
2.62
1.93
1.42
1.18
38
18.99
11.28
6.94
5.05
4.00
2.88
2.10
1.53
1.26
40
12.63
7.73
5.59
4.41
3.16
2.28
1.65
1.35
42
14.08
8.56
6.17
4.85
3.45
2.48
1.77
1.44
44
15.63
9.46
6.78
5.31
3.76
2.68
1.90
1.53
46
17.27
10.40
7.44
5.80
4.08
2.89
2.04
1.63
48
19.02
11.41
8.12
6.32
4.42
3.12
2.18
1.73
50
12.47
8.85
6.86
4.79
3.35
2.33
1.84
52
13.59
9.62
7.44
5.16
3.60
2.48
1.95
54
14.77
10.42
8.04
5.56
3.86
2.64
2.07
56
16.01
11.27
8.67
5.98
4.13
2.81
2.19
58
17.31
12.15
9.34
6.41
4.41
2.99
2.32
60
18.67
13.08
10.03
6.86
4.71
3.17
2.46
62
20.10
14.05
10.75
7.34
5.01
3.36
2.59
64
15.06
11.51
7.83
5.33
3.56
2.74
66
16.11
12.29
8.34
5.66
3.77
2.88
68
17.21
13.11
8.87
6.00
3.98
3.04
70
18.36
13.96
9.42
6.36
4.20
3.20
72
19.54
14.84
9.99
6.73
4.43
3.36
74
15.75
10.58
7.11
4.66
3.53
76
16.70
11.20
7.50
4.90
3.70
78
17.68
11.83
7.90
5.15
3.88
80
18.70
12.48
8.32
5.41
4.07
82
19.75
13.16
8.75
5.68
4.26
84
13.86
9.20
5.95
4.45
86
14.58
9.65
6.23
4.65
88
15.32
10.13
6.52
4.86
90
16.08
10.61
6.81
5.07
92
16.87
11.11
7.12
5.29
94
17.68
11.62
7.43
5.51
96
18.51
12.15
7.75
5.74
98
19.36
12.68
8.08
5.97
100
20.24
13.24
8.41
6.21
.50" Water Column have been Added To Static Pressure to Account for System Loss
Static Pressures are Calculated Using a 1.15 Factor Applied to Shedd's Data
GRAIN
DEPTH
FEET
Static Pressure (inches of water column)
Airflow Rate (cfm per bushel)
