5. Operation
PNEG-012 Vane Axial Heater 23
BTUs per Gauge Pressure (PSI) - Propane Models (Approximate)
High Temperature
Low Temperature
Gauge Pressure (PSI) Required to Maintain Temperatures (Approximate)
(Shaded Areas Represent Low Temperature Settings)
Diameter
Operating Pressure (PSI)
2 4 6 8 10 12 14 16 18 20
24", 26" and 28" 892,353 1,218,775 1,496,555 1,734,425 1,940,412 2,121,835 2,285,304 2,436,723 2,581,288 2,723,487
Diameter
Operating Pressure (PSI)
2 4 6 8 10 12 14 16 18 20
All Models 163,902 223,857 274,877 318,568 356,402 389,725 419,750 447,561 474,114 500,232
Fan
Model
Static
Pressure
Heat Rise °F
60 80 100 120 140 160 180
3 HP-18"
1" 10 2 3 4 5 7 8
2" 6 10 2 2 3 4 5
3" 2 3 5 6 8 10 14
5 HP-24"
1" 10 1 1 1 2 2 3
2" 6 10 14 1 1 1 2
3" 2 3 4 6 8 10 14
7 HP-24"
1" 2 3 4 5 7 9 12
2" 2 2 3 4 5 6 8
3" 1 1 2 3 3 4 5
4" 5 9 14 20 1 1 2
10 HP-24"
1" 2 3 5 6 8 12 14
2" 2 3 4 5 7 9 12
3" 1 2 3 4 5 6 7
4" 12 20 1 1 2 3 3
5" 4 7 12 15 20 1 1
15 HP-26"
1" 3 4 6 9 12 14 20
2" 2 3 5 7 10 12 16
3" 2 3 4 5 7 9 12
4" 1 2 3 3 5 6 7
5" 14 1 1 2 2 3 4
15 HP-28"
1" 4 7 10 14 20 25 30
2" 3 6 8 12 16 20 25
3" 3 5 7 10 14 18 20
4" 2 4 5 8 10 14 16
5" 2 3 4 5 7 9 12
