6. Layouts

40

PNEG-1816 33' Dura-Lok Plank and Support Manual

33' Plank Layout for Manual

Plank #

Plank Length

In Inch

In Metric

1

9'-3"

111

281.94

2

12'-4"

148

375.92

3

14'-11"

179

454.66

4

17'-0"

204

518.16

5

18'-6"

222

563.88

6

20'-1"

241

612.14

7

21'-6"

258

655.32

8

22'-9"

273

693.42

9

23'-10"

286

726.44

10

24'-11"

299

759.46

11

25'-10"

310

787.4

12

26'-8"

320

812.8

13

27'-6"

330

838.2

14

28'-2"

338

858.52

15

28'-10"

346

878.84

16

29'-5"

353

896.62

17

29'-11"

359

911.86

18

30'-5"

365

927.1

19

30'-10"

370

939.8

20

31'-2"

374

949.96

21

31'-6"

378

960.12

22

31'-9"

381

967.74

23

31'-11"

383

972.82

24

32'-1"

385

977.9

25

32'-3"

387

982.98

26

32'-3"

387

982.98

27

32'-3"

387

982.98
