4. Monorail Installation
18 PNEG-1816 33' Dura-Lok Plank and Support Manual
Monorail “Rail and Leg Spacing”/“Full Floor Leg Quantity” for 33' Bin Diameter
4.00"
Ring
2.66"
Ring
Eave Height (ft.) Rail Spacing
Reference
Page
Leg Spacing Leg Qty
3 4 11 26 See Page 36 27 250
4 6 16 26 See Page 36 24 280
5 8 22 26 See Page 36 21 320
7 10 27 26 See Page 36 19 350
9 12 33 22 See Page 34 20 370
10 14 38 22 See Page 34 19 390
11 16 43 22 See Page 34 18 410
13 18 48 20 See Page 32 18 450
14 20 54 20 See Page 32 17 470
16 22 59 18 See Page 30 17 510
17 24 64 18 See Page 30 17 510
19 26 70 18 See Page 30 16 540
20 28 75 17 See Page 28 16 560
22 30 81 16 See Page 26 16 580
23 32 86 16 See Page 26 15 620
