PNEG-524 Roof Exhaust Fan 15
6. PARTS LIST
18" Roof Exhauster Parts
Figure 6A 18" Roof Exhauster Parts Breakdown.
18" Roof Exhauster Parts
Ref # Part # Description Qty
1 F-942 Control box lid 1
2 FH-4429-1 Lid clamp 2
3 F-6864 Control box wrapper 1
4 MIS-6680 18" exhauster weldment 1
5 F-6701 Motor support bracket 1
6 F-953 Fan grill guard 1
7 MIS-6689 18" fan blade 1
8 MIS-6688 .5 H. P. motor 1
9 MIS-6679 Mounting Flange 1
