96374 v.4.0
5
Backing up the Factory
Tune
Warning: Do not unplug the Banks
OttoMind Programmer while it
is installing the Banks OttoMind
performance tune.
4.
Using the keypad, highlight ‘Tune
It’ and press the ‘Enter’ button on the
keypad.
5.
Follow the instructions listed on
the screen. Then press any key to
continue.
6.
Read the Disclaimer on the screen,
then press any key to continue.
WARNING: THE BANKS OTTOMIND
MUST BE USED WITH FACTORY
TUNE, OTHERWISE DAMAGE MAY
RESULT TO YOUR VEHICLE. IF
YOU ARE NOT SURE ABOUT YOUR
TUNE, CONTACT GALE BANKS
ENGINEERING. (See Figure 3)
7.
if you want to continue, press the
Enter button for YES. Or press the Esc
button for NO. (See Figure 4)
Note: If the ignition key is not turned
on then the following screen will be
seen. (See Figure 5) Check to see that
the Ignition is in the Run position, then
do step 4 thru 7.
8.
Make sure fuse 21 was removed
from the instrument cluster as
directed in section 1, step 1. see
Figure 6 and Figure 7.
Figure 2
Ottomind 03-05 2.07
Tune It
Diagnostics
Options
Figure 3
Disclaimer
THE BANKS OTTOMIND MUST BE
USED WITH FACTORY TUNE, OTHER-
WISE DAMAGE MAY RESULT TO YOUR
VEHICLE. IF YOU ARE NOT SURE
ABOUT YOUR TUNE, CONTACT GALE
BANKS ENGINEERING.
Figure 4
Important
Do you want to
continue?
Press Enter for YES
Press Esc for NO
Figure 5
Tune it
No Response.
Is ignition ON?
Press any key…
Figure 6
IPC Fuse Warning
Fuse 21 (inside, not underhood)
instrument cluster power (IPC)
must be pulled or damage to the
vehicle controller will
occur.
ESC = Exit to Menu
Enter = Continue
