10
96374 v.4.0
The diagnostic feature on the Banks
OttoMind programmer allows you
to check and clear Service Engine
soon (ses) light, check and clear
Trouble codes, view Real Time Data,
read Abbreviations and assist in
Troubleshooting. Also, the diagnostic
section will allow you to check the
key parameters in your vehicle in
real time. This feature can be helpful
in diagnosing sensors and other
equipment in your vehicle.
Note: Fuse 21 does not need to be
removed for diagnostics.
1.
Open the Diagnostic menu by
highlighting then press ENTER. (See
Figure 14). The Options menu
displays the available parameters and
specific data assigned to your Banks
OttoMind programmer. Scroll through
the list using the UP and DOWN
arrow keys to view the Options menu
contents. See Figure 15
2.
Highlight Trouble codes then press
ENTER to view any stored diagnostic
trouble codes.
3.
Highlight DTc Information then
press ENTER to view stored diagnostic
trouble codes. Under the DTc
information menu titled General Data,
select from the three available options
by highlighting and then press ENTER.
See Figure 16
-DTc ALL- The listing of all stored
diagnostic trouble codes.
-Specific DTc- Use this to view a
specific diagnostic trouble code.
-DTc not Ran Scc- Use this to view
diagnostic trouble codes that were not
performed during the DTc ALL check.
4.
To remove diagnostic trouble codes
highlight Erase DTc’s and press ENTER.
Highlight Reset and then press
ENTER. The Banks OttoMind will reset
any available trouble codes. Once
the erasure of the trouble codes is
complete the screen will flash, ‘Reset
completed. Press ESc to cont’. See
Figure 17.
NOTE: The PCM performs tests of
Section 4
DIAGNOSTIC SECTION
Figure 14
Ottomind 03-05 2.01
Tune It
Diagnostics
Options
Figure 15
Engine Control Unit
Trouble Codes
Real Time Data
Abbreviations
Troubleshooting
Figure 16
General Data
DTC All
Specific DTC
DTC not Ran SCC
Figure 17
Trouble Codes
Reset completed
Press ESC to cont
