96508 v.7.0
3
limited to a period of 90 days from
purchase. All products that are in
question of warranty must be returned
shipping prepaid to the SELLER and
must be accompanied by a dated proof
of purchase receipt. All warranty claims
are subject to approval by Gale Banks
Engineering Inc.
WARNING: The PDA may be
susceptible to damage as a
result of extended exposure
to sunlight, heat or extreme
cold. It is highly recommended
that the PDA be removed from
it’s mounting location if the
vehicle will be subjected to high
concentrations of sunlight, heat
or cold for an extended period
of time. Gale Banks Engineering
is not responsible for damage to
PDAs resulting from exposure
conditions.
Under no circumstance shall the SELLER
be liable for any labor charged or travel
time incurred in diagnosis for defects,
removal, or reinstallation of this product,
or any other contingent expense.
Under no circumstances will the SELLER
be liable for any damage or expenses
incurred by reason of the use or sale of
any such equipment.
In the event that the buyer does
not agree with this agreement:
The buyer may promptly return
this product, in a new and
unused condition, with a dated
proof-of-purchase, to the place-
of-purchase within thirty (30)
days from date-of-purchase for a
full refund, less shipping and/or
restocking fee.
The installation of this product
indicates that the buyer has read
and understands this agreement
and accepts it’s terms and
conditions.
Table of Contents
Introduction. . . . . . . . . . . . . . . . . . . . 4
General Installation Practices . . . . 5
Section 1 . . . . . . . . . . . . . . . . . . . . . . 7
Installation of Wiring Harness,
Connections and Six-Gun Diesel Tuner
Section 2 . . . . . . . . . . . . . . . . . . . . . 11
Mounting the (optional) Docking Station
and connecting the Banks PowerPDA
Section 3 . . . . . . . . . . . . . . . . . . . . . 14
Installation of the (optional) Six-Gun
Selector Switch
Section 4 . . . . . . . . . . . . . . . . . . . . . 19
Optional Thermocouple Installation
(Required for optional Banks PowerPDA)
Section 5 . . . . . . . . . . . . . . . . . . . . . 20
Automatic Transmission Learning
Section 6 . . . . . . . . . . . . . . . . . . . . . 21
checking Engine Performance
Section 7 . . . . . . . . . . . . . . . . . . . . . 22
Troubleshooting
Section 8 . . . . . . . . . . . . . . . . . . . . . 25
clearing Learned Information
Section 9 . . . . . . . . . . . . . . . . . . . . . 26
Removal of the Six-Gun Diesel Tuner
Section 10 . . . . . . . . . . . . . . . . . . . . 29
Placement of the Banks Power Decals
