10
97276 v.1.0
Section 4
InSTALLInG BAnKS AUToMInD FLASH CALIBrATIon ProGrAM
WArnInG: Do not unplug
the Banks AutoMind Flash
Programming Module while
uploading or downloading a
calibration. Doing so can damage
the vehicles eCM.
–IMPORTANT- Turn the ignition ON,
but DO NOT start the engine. Apply
the parking brake to turn off lights and
conserve the battery. (Not necessary
on some models that do not activate
parking lights when the ignition is
turned ON).
1.
Push the AutoMind Flash button
on the Banks iQ screen in the ‘Mode
Select’ menu. See Figure 3.
NOTE: It will take a moment for the
AutoMind Flash Programming Module
to read the vehicle ECM and to display
the Tuning menu. See Figure 4.
2.
Select ‘PROGRAM VEHIcLE’ to begin
the calibration process. See Figure 5.
3.
Select ‘QUIcK TUNE’ to choose
from calibrations that retain the
factory values for Speed Limiter, Rev
Limiter, Tire Size, Shift Characteristics,
Gear Ratio and Fan Activation
Temperature. Select ‘ADVANcED
TUNE’ to adjust any of these
parameters. See Figure 6.
4.
Select desired calibration to install.
See Table 1 for a list of tune levels
and description.
CAUTIon: The Banks AutoMind
Flash Calibration does not
increase the load capacity of your
vehicle. Gross combined Weight
rating Specifications should
always be adhered to.
If you selected ‘QUICK TUNE’
calibration skip to step 9.
5.
If selecting ‘ADVANCED TUNE’,
select the available Tune calibration.
You may modify Limited available
parameters within the calibration by
pressing the ‘Options’ button. See
Figure 7.
Figure 4
