Section 4
INSTALLING BANKS AUTOMIND CALIBRATION PROGRAM
WARNING: Do not unplug the
Banks AutoMind Programmer
while uploading or downloading a
program. Doing so can damage the
vehicles ECM.
–IMPORTANT- Turn the ignition ON,
but DO NOT start the engine. Apply
the parking brake to turn off lights and
conserve the battery. (Not necessary
on some models that do not activate
parking lights when the ignition is turned
ON).
1.
Using the keypad, scroll up or down
to highlight ‘TUNE VEHICLE’ and press
the ‘OK’ button on the keypad. See
Figure 3.
2.
Select ‘QUICK TUNE’ to choose from
calibrations that retain the factory values
for Speed Limiter, Rev Limiter, Tire Size,
Shift Characteristics, Gear Ratio and
Fan Activation Temperature. Select
‘ADVANCED TUNE’ to adjust any of these
parameters. Press ‘OK’ once you have
made your selection. See Figure 4.
3.
Select desired calibration to install
and press the ‘OK’ button to continue.
See Table 1 for a list of tune levels and
description.
CAUTION: The Banks AutoMind
Programmer does not increase
the load capacity of your vehicle.
Gross combined Weight Rating
Specifications should always be
adhered to.
4.
Follow the on screen instructions
and turn the ignition key ‘ON/OFF’ when
prompted by the programmer, but do
not start the engine.
5.
The Vehicle stock file will be saved to
the Banks AutoMind Programmer. Press
‘OK’ to continue.
If you selected ‘QUICK TUNE’
calibration skip to
step 8
.
6.
In the following screen you may
modify Limited available parameters
within the calibration
The following parameters may be
modified:
-Speed Limiter
-Rev Limiter
-Tire Size
-Shift Points
-Shift Pressure
-Gear Ratio
-Fan activation Temperature
-Torque Management (MGMT)
NOTE: Parameter availability may
vary by vehicle make and fuel type.
WARNING: Only Adjust/Remove
speed and/or rev limiter higher
than stock if your vehicle is
equipped with appropriately
speed-rated tires.
CAUTION: Do Not disable ‘Torque
MGMT’ if towing or carrying a load
with the vehicle. Doing so could
damage vehicle drivetrain.
-IMPORTANT- Verify your vehicles Gear
ratio before altering the ratio with the
Banks AutoMind Programmer. Reference
your vehicle’s owner’s manual or
vehicle’s dealer for correct gear ratio.
An incorrect gear ratio entry may alter
Figure 3
Figure 4
