Section 7
DATA LOGGING
The Data Acquisition feature allows
you to view various sensors that are
monitored through your vehicle’s ECM,
and record data during acceleration
runs.
1.
Plug in your Banks AutoMind
Programmer and turn the key to the
ON position. Do not start the vehicle.
2.
After the welcome screen, scroll
up or down in the main menu screen
and highlight to select ‘ADDITIONAL
FEATURES’ and press the ‘OK’ button.
3.
In the ‘ADDITIONAL FEATURES’
submenu highlight to select ‘DATA
Logging’ and press ‘OK’.
4.
In the Data Logging Menu you will
have the option to ‘Log by Speed’, ‘Log
by Distance’, or ‘Advanced’. Highlight
to select the desired Data Logging
Feature and press ‘OK’.
Log by Speed - Log the vehicles 0
to 40 through 0 to 70 MPH run times,
review Last Run History and the Best
Times History. Log by Speed will begin
once a selection is made and the
vehicle is in motion.
Log by Distance - Log the distance
runs for your vehicle from 60ft through
1/4mile. Review the Last Run History
and the Best Speed & Time History.
Log by Distance will begin once a
selection is made and the vehicle is in
motion.
Advanced - This option will allow you
to view various sensor values that are
available through the vehicle’s ECM.
5.
After selecting the Advanced
feature, use the UP and DOWN button
keys to view all your options. Select
the items you would like to monitor
by highlighting them and pressing the
‘OK’ button. An arrow will appear next
to the options you have selected.
NOTE: To unselect, highlight the item
you have already selected and press
the ‘OK’ button.
6.
Once you are done selecting, press
the ‘Left button’ key to continue.
7.
To start the sensor valve display,
highlight to select ‘START DISPLAY’
and press ‘OK’ button to continue.
8.
Turn the vehicle ON, then press the
‘OK’ button to continue.
9.
The monitor will setup your
configurations. The options status you
have selected will be displayed on the
screen.
NOTE: Screen will only display 4 items.
10.
To Exit data logging press the
‘OK’ button at anytime during the data
logging.
-END, SECTION 7-
