Page 8

8
97270 v.4.0
1.
Do not activate any electrical
accessories while installing the Banks
AutoMind calibration. Ensure that
there are no electronic devices wired
or plugged into the vehicle that can
cause a substantial voltage drop,
which might be activated during the
installation process. Please contact
a Banks dealer if uncertain about
devices that are on your vehicle.
2.
Certain cellular phones or
radio equipment might also cause
interference, please remove or turn
such devices off.
3.
Unless instructed in the installation
steps, never turn the ignition key
OFF while the Banks AutoMind
programmer is plugged into the OBDII
connection port.
WARNING: Unplugging the
Banks AutoMind Programmer
while uploading or
downloading a calibration can
damage the vehicles ECM.
4.
Ensure that the factory “stock”
calibration is in the vehicle’s ECM
before installing the Banks AutoMind
calibration. If you are uncertain if your
vehicle is in stock condition tune then
have the vehicle’s ECM reflashed by
your vehicle’s make dealer.
NOTE: Dealer re-flashes are the same
as stock factory calibration.
WARNING: The Banks AutoMind
calibration should not be installed
over a non-factory/aftermarket
performance tune, and except
in rare sases should not be used
in conjunction with other tuning
devices such as chips or plug in
modules of any kind.
COMBINING DEVICES IS DONE AT
THE USER’S OWN RISK
Connecting to OBD II
5.
Locate the OBD II connection port
in your vehicle. The OBD II connection
port is located under the dash panel
and can be located on either side of
the steering wheel.
6.
Connect your Banks AutoMind
Programmer to the vehicle OBD II
connection port.
NOTE: When the OBD II connector
is plugged in, the Banks AutoMind
programmer will automatically power
on and illuminate its start up screen.
If the Banks AutoMind programmer
does not come on then check the fuse
to the cigarette lighter or OBD II in
the fuse panel. The screen will display
Banks
(See Figure 2), then display the
AutoMind Warning and Disclaimer.
-END, SECTION 3-
Figure 2
