25-1/8”
(638)
22”
(559)
20-3/8”
(518)
27-1/2”
(699)
24 1/2”
(622)
63”
(1600)
37-5/8”
(956)
1-1/4”
(32)
6”
(152)
front view side view back view
Form # MCO0956
ACP’s commitment to quality may mean a change in specification without notice. Product of the U.S.A. © 2012 ACP Inc.™ Printed in the U.S.A.
AIA File #:
Specification #:
225 49th Ave. Dr. SW Cedar Rapids, IA 52404 U.S.A. | 800-233-2366 | 319-368-8120 | Fax: 319-368-8198 | www.acpsolutions.com
Specifications
Model
MXP22 UPC Code 728028043273
Cooking Power*
2000W
Forced
Convection
2200W
Microwave
3000W
Infra-red radiant
Configuration Countertop
Programmable Control Pads 10
Total Programmable Settings 360
Power Levels
11
Max. Cooking Time 60:00
Program Menu Multi-level menu capability
Defrost Yes, microwave only, power level 2
Time Entry Option Yes
Microwave Distribution Double side oscillating antenna
Magnetrons 2
Display VFD
Stackable Yes
Stage Cooking Yes, 4
Door Opening Pull down, ergonomic handle
Automatic Voltage Sensor Yes
USB Port Yes
Temperature Range 200 o - 520 o F (95 o - 270 o C)
Air Filter 2 removable, with clean filter reminder
0-100% Fan Speed
Rack
1 rack position, removable
Exterior Dimensions H 20 3/8” (518) W 25 1/8” (638) D** 27 1/2”(699)
Cavity Dimensions H 10” (254) W 16” (406) D 15” (381)
Door Depth 37 5/8” (956), drop down door
Usable Cavity Space 1.38 cubic ft. (39 liter)
Exterior Finish Stainless steel
Interior Finish Stainless steel
Power Consumption 5700 W, 27.4A
Power Output* 2200 W* Microwave
Power Source 208 - 240 V, 60 Hz, 30 A single phase
Plug Configuration / Cord NEMA 6-30 5 ft. (1.5 m)
Frequency 2450 MHz
Product Weight 150 lbs. (68 kg.)
Ship weight (approx.) 175 lbs. (79 kg.)
Shipping Carton Size H 34 3/4” (883) W 28 1/4” (717) D 32 1/2” (826)
Specifications
Oven shall combine three cooking modes: forced
convection, microwave and infra-red radiant for high
speed cooking. Icon operated control panel shall be program-
mable with the ability to program up to 360 menu items and shall
have multi-level menu capability. Programs shall be automati-
cally updated using a USB port that is compatible with standard
USB flash drives. Display shall be VFD. There shall be 11 power lev-
els, 4 cooking stages and defrost mode. Microwave output shall
be 2200 watts and distributed from two magnetrons located on
each side of the cavity. An automatic voltage sensor shall accom-
modate both 208 and 240 volts. Oven shall provide a tempera-
ture range from 200
o - 520 o F (95 o - 270 o C) in 5 o increments. The
convection fan shall distribute the heat throughout the cavity to
further reduce cook times. Fan speed can be programmed from 0
to 100% for menu flexibility. The infra-red radiant shall have 3000
watt output and deliver heat from the bottom of the oven. This
element shall be hinged for easy cleaning of the oven floor. The
oven cavity shall have a 1.38 cubic ft. (39 liter) capacity and use
standard metal cookware. Maximum microwave cooking time
shall be 60 minutes. Oven shall have a stainless steel exterior and
be stackable. Oven cavity shall be stainless steel construction with
stainless oven door. Drop down door shall open below oven rack
for full access to the cavity. The two side air filters shall be remov-
able for easy cleaning and have a “clean filter” reminder feature. A
removable, one position rack shall be included. Microwave oven
shall comply with standards set by the U.S Department of Health
and Human Services, ETL listed for safety and sanitation.
Included Accessories:
l Oven paddle
Optional Accessories
l Pizza stone 14 3/8” (365mm) dia.
l Leg kit - set of four 4” (102mm) legs
l Non-stick baskets - set of two
- 10” x 12” x 1” (254 x 305 x 25mm) size
- 6” x 12” x 3/4” (152 x 305 x 19mm) size
l Stainless carts/equipment stands 24” (610) and 30” (762)
Warranty
Warranty Certificate for this product can be found on the ACP, Inc.
website at:
www.acpsolutions.com/warranty
Service
All products are backed by the ACP, Inc.
24/7 ComServ Support Center. Measurements in ( ) are millimeters
* IEC 60705 Tested
** Includes handle
Menumaster® Commercial MXP22 | High Speed Combination Oven
