4. Features
• GUI display and USB mouse control
• Gmail integration supports notification through Google mail server and any other mail support
• local and remote control completely independent
• H.264 video compression technology
o highly improves video quality for live viewing and recording
o recording file size is minimized for longest recording time
o lower bit rate required for fastest network transfer
• multiplex: allows live display, recording, playback, and backup at the same time
• supports video output for composite & VGA simultaneously
• backup function: supports USB 2.0 flash drive backup
• advanced mobile surveillance via free EAGLE EYES software:
o Compatible with iPad, iPhone, Android Tablet, Android Smartphone, Blackberry,
Windows Mobile and Symbian
• remote surveillance on PC for operating systems:
o compatible with Windows & MAC operating system
o for web browsers: compatible with Internet Explorer, Mozilla Firefox, Google Chrome
& Safari
o for CMS software: company-developed and free software "Video Viewer, on both
Windows and MAC operating systems
o also via Apple's media player, QuickTime
• intelligent motion trigger recording
o advanced motion detection
o scheduled motion detection recording (with 1 adjustable parameter)
o quick search function (time/motion/alarm)
o only the channel with an event will be recorded to effectively save a significant
amount of hard disc space
• multi-language OSD: English, French, Dutch, German, Italian, Portuguese, Spanish, Czech,
Hungarian and Greek
• A/V support: supports 4 audio inputs and 1 audio output for sound recording
• full user manual: English, French, German, Spanish
• supports SATA HDD
• PTZ control: supports PELCO-D protocol
• alarm I/O: 4 inputs, 1 output
• supports daylight-saving function
• supports manual / timer / motion / network recording functions
• system auto recovery after power reconnected
• hard disks in option: 500GB (HD500GB/S) or 1TGB (HD1TB/S) (not included)
• supports TCP/IP, PPPoE, DHCP and DDNS network connection
5. Overview
Refer to the illustrations on page 2 of this manual.
Front panel
LED
indications
HDD
reading or recording activities on the hard disk
ALARM
an alarm was triggered
TIMER
timed recording is enabled
PLAY
the DVR is in playing mode
POWER
DVR power is on
NAVIGATE
Press one of the four positions on the navigate button to move the
cursor up (
), down ( ), left ( ) or right ( ).
In play-back mode, press the buttons to play/pause ( ), stop
( ), fast rewind ( ) or fast forward ( ) the play-back file.
In setting mode, press the up ( ) or down ( ) button to change
the setting in the menu.
MENU Press to enter the main menu.
ENTER Press to confirm settings
LIST
List the information of the recorded files.
QUICK SEARCH / RECORD / MOTION / ALARM / TIMER / FULL LIST
