Velleman DVR8H1 Quick Installation Guide User Manual
Page 2
DVR8H1
07/03/2013
©Velleman nv
2
FRONT VIEW – VOORZIJDE – VUE FRONTALE
VISTA FRONTAL – VORDERANSICHT
REAR VIEW – ACHTERZIJDE – VUE ARRIÈRE VISTA POSTERIOR –
HINTERANSICHT
A
B
HDD not included - Harde schijf
niet meegeleverd - Disque dur
non inclus - Disco duro no
incluido - Festplatte nicht
mitgeliefert
power supply
data bus (SATA)
voeding
databus (SATA)
alimentation
bus de données (SATA)
alimentación
bus de datos (SATA)
Stromversorgung
Datenbus (SATA)
Figure 1
