HAA85BL
v2 15/11/2013 VELLEMAN 9
CODE pressing until you hear confirmation beeps.
Refreshing the system
When choosing a different operation mode (see above), the system will reset and clear all values except for the
master code.
NOTE: Make sure the user code and the master code are both 4 digits long when operating in single user mode.
8. Programming and Use of the Keypad – Operation Examples
A) Programming procedures
a. Your HAA85BL is programmed from the keypad. All programmed information is stored in the non-volatile
memory.
b. Set the keypad into programming mode first with the master code and press to validate.
NOTE: Use the DAP jumper to set the keypad into programming mode in case you forgot the master code.
See section 4 Reset master code.
c. Go to a location and program the options. See “6. Programming the Keypad – Summary Chart”.
d. Program the options until all options are programmed. Repeat the programming of an option in case of a
wrong entry.
LOCATION 1 OPTION
…
LOCATION n OPTION n
e. Exit the programming mode with . All input information has been saved.
B) Single user mode operation – Example
1. Requirements
a. Single user mode
b. Change the factory-set master code 0000 to a personal master code 3289
c. Set user code 1 to 8321
d. Set user code 2 to 6854
e. Set user code 3 to 9270
f. Set output 1 to momentary mode, 1 second
g. Set output 2 to start / stop mode
h. Set output 3 to start / stop mode
i. Set the keypad to lock itself during 15 minutes after 10 successive false codes
2. Programming – Setting the above requirements into the keypad
Program mode with factory-set master code
Single user mode*
3289 stored as new personal master code and super user code
8321 stored as user code1 with duress code function for output 1
6854 stored as user code 2 for output 2
