Atlas SCR User Guide January 2008 – Rev 3
Page 14
Appendix B - Technical Specifications
All values are at 25
°C unless otherwise specified.
Parameter Minimum Typical Maximum Note
Peak test current into S/C 100mA 120mA 1
Peak test voltage across O/C 12.0V 12.5V 1
Gate trigger current range (I
GT
) 0.1mA 90mA
Battery type GP23A 12V Alkaline
Battery voltage range 8.5V 12V
Battery voltage warning threshold 8.5V
Inactivity power-down period 20 secs (2 secs for single screen results)
Dimensions (excluding test leads) 103 x 70 x 20 mm
Operating temperature range 0
°C
50
°C
2
1. Between any pair of test clips.
2. Subject to acceptable LCD visibility.
