D9T Track-Type Tractor Specifications
Engine Weights Hydraulic Controls
Engine Model Cat ® C18 ACERT™ Operating Weight 50 098 kg 110,447 lb Pump Type Piston-type pump
Gross Power 334 kW 448 hp
Net Power
ISO 9249 306 kW 410 hp
ISO 14396 329 kW 441 hp
SAE J1349 306 kW 410 hp
EU 80/1269 306 kW 410 hp
DIN 70020 428 PS
Bore 145 mm 5.7 in
Stroke 183 mm 7.2 in
Displacement 18.1 L 1,106 in 3
• Engine ratings apply at 1,833 rpm.
• Net power advertised is the power available
at the flywheel when the engine is equipped
with fan at max speed, air cleaner, muffler
and alternator.
• No derating required up to 2286 m (7,500 ft)
altitude. High altitude attachment available
for greater than 2286 m (7,500 ft).
Service Refill Capacities
Fuel Tank 889 L 235 gal
Cooling System 101 L 26.7 gal
Engine Crankcase* 34 L 9 gal
Powertrain 164 L 43.4 gal
Final Drives (each) 15 L 3.9 gal
Roller Frames (each) 45 L 11.7 gal
Pivot Shaft 30 L 7.9 gal
Compartment
Hydraulic Tank Oil
89 L 23.5 gal
(only)
*With oil filters.
Shipping Weight 37 792 kg 83,317 lb
• Operating Weight: Includes hydraulic
controls, blade tilt cylinder, coolant,
lubricants, full fuel tank, ROPS, FOPS cab,
SU-Blade, Single-Shank Ripper, 610 mm
(24 in) ES shoes, and operator.
• Shipping Weight: Base machine chassis
with cab, pivot shaft, roller frames, track
and ROPS.
Undercarriage
Shoe Type Extreme Service
Width of Shoe 610 mm 24 in
Shoes/Side 43
Grouser Height 84 mm 3.3 in
Pitch 240 mm 9.44 in
Ground Clearance 596 mm 23.5 in
Track Gauge 2250 mm 89 in
Length of Track 3474 mm 11 ft 5 in
on Ground
Ground
4.24 m 2 6,569 in 2
Contact Area
Track Rollers/Side
8
Number of 1 per side (optional)
Carrier Rollers
• Positive Pin Retention Track.
geared from flywheel
Pump Output 387 L/min 102 gal/min
(Steering)
Pump Output
226 L/min 60 gal/min
(Implement)
Tilt Cylinder Rod
140 L/min 37 gal/min
End Flow
Tilt Cylinder Head
188 L/min 50 gal/min
End Flow
Bulldozer Relief
26 200 kPa 3,800 psi
Valve Setting
Tilt Cylinder Relief
19 300 kPa 2,800 psi
Valve Setting
Ripper (Lift) Relief
26 200 kPa 3,800 psi
Valve Setting
Ripper (Pitch) Relief 26 200 kPa 3,800 psi
Valve Setting
Steering
40 500 kPa 5,875 psi
Tank Capacity 89 L 23.5 gal
• Steering Pump output measured at
2,239 rpm and 30 000 kPa (4,351 psi).
• Implement Pump output measured at
1,800 rpm and 20 000 kPa (2,900 psi).
• Electro-hydraulic pilot valve assists
operations of ripper and dozer controls.
Standard hydraulic systems includes
four valves.
• Complete system consists of pump, tank
with filter, oil cooler, valves, lines, linkage
and control levers.
Transmission
1 Forward 3.9 km/h 2.4 mph
2 Forward 6.8 km/h 4.2 mph
3 Forward 11.7 km/h 7.3 mph
1 Reverse 4.7 km/h 2.9 mph
2 Reverse 8.4 km/h 5.2 mph
3 Reverse 14.3 km/h 8.9 mph
1 Forward – 716.5 N 161 lbf
Drawbar Pull (1000)
2 Forward –
400.5 N 90 lbf
Drawbar Pull (1000)
3 Forward –
222.5 N 50 lbf
Drawbar Pull (1000)
14
