23 385C L Hydraulic Excavator specifications
Load at
Maximum Reach Load Point
Height Load Radius
Over Front Load Radius
Over Side
General Purpose Boom Lift Capacities
* Indicates that the load is limited by hydraulic capacity rather than tipping capacity. Lift capacity ratings are based on SAE standard J1097.
Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity.
3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft
m
ft
12.0 m kg *6300 *6300 9.28
40.0 ft lb *14,150 *14,150 29.67
10.5 m kg *5620 *5620 10.78
35.0 ft lb *12,500 *12,500 34.89
9.0 m kg *14 790 *14 790 *5280 *5280 11.80
30.0 ft lb *32,250 *32,250 *11,700 *11,700 38.44
7.5 m kg *17 910 *17 910 *15 500 15 360 *13 910 10 680 *5150 *5150 12.50
25.0 ft lb *38,700 *38,700 *33,600 32,750 *26,900 22,450 *11,350 *11,350 40.86
6.0 m kg *25 120 *25 120 *19 840 *19 840 *16 590 14 830 *14 410 10 600 *5180 *5180 12.94
20.0 ft lb *53,900 *53,900 *42,750 *42,750 *35,900 31,750 *31,250 22,500 *11,400 *11,400 42.39
4.5 m kg *28 750 28 120 *21 870 19 550 *17 790 14 100 *15 070 10 280 *5350 *5350 13.16
15.0 ft lb *61,750 60,800 *47,150 42,100 *38,450 30,250 *32,600 21,900 *11,750 *11,750 43.14
3.0 m kg *27 280 24 770 *23 540 18 170 *18 840 13 330 *15 660 9890 *5660 5490 13.16
10.0 ft lb *67,400 55,000 *50,800 39,100 *40,700 28,600 *33,800 21,100 *12,450 12,100 43.19
1.5 m kg *22 520 22 520 *24 460 17 120 *19 490 12 690 *15 980 9530 *6140 5610 12.96
5.0 ft lb *55,350 51,650 *52,850 36,850 *42,100 27,200 *34,500 20,350 *13,500 12,350 42.52
Ground kg *27 810 23 490 *24 480 16 530 *19 570 12 260 *15 850 9280 *6830 6050 12.53
Line lb *66,150 50,500 *52,950 35,550 *42,250 26,300 34,100 19,850 *15,050 13,350 41.12
–1.5 m kg *17 080 *17 080 *29 400 23 580 *23 560 16 350 *18 890 12 090 *14 940 9210 *7840 6930 11.87
–5.0 ft lb *39,550 *39,550 *63,850 50,650 *50,950 35,150 *40,700 25,950 *31,900 19,750 *17,300 15,350 38.89
–3.0 m kg *19 990 *19 990 *29 890 *29 890 *26 600 24 060 *21 580 16 530 *17 150 12 210 *8740 8530 10.90
–10.0 ft lb *45,350 *45,350 *68,550 *68,550 *57,650 51,650 *46,550 35,500 *36,750 26,200 *19,150 18,950 35.64
–4.5 m kg *26 290 *26 290 *22 390 *22 390 *18 110 17 070 *13 480 12 690
–15.0 ft lb *56,900 *56,900 *48,200 *48,200 *38,700 36,750 *27,850 27,400
–6.0 m kg *15 790 *15 790 *11 660 *11 660
–20.0 ft lb *23,250 *23,250
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤ ➤ ➤
➤
➤
➤
➤ ➤ ➤
➤
BOOM – 8.4 m (27'7")
STICK – 2920 mm (9'7") BUCKET – 2260 mm (89") GP with HD long tips
SHOES – 900 mm (36") double grouser UNDERCARRIAGE – Long
HEAVY LIFT – On
* Indicates that the load is limited by hydraulic capacity rather than tipping capacity. Lift capacity ratings are based on SAE standard J1097.
Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity.
3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft 12.0 m/40.0 ft
m
ft
12.0 m kg *5580 *5580 9.93
40.0 ft lb *12,550 *12,550 31.85
10.5 m kg *12 750 *12 750 *4990 *4990 11.31
35.0 ft lb *11,100 *11,100 36.68
9.0 m kg *13 910 *13 910 *4700 *4700 12.28
30.0 ft lb *30,300 *30,300 *10,400 *10,400 40.03
7.5 m kg *14 700 *14 700 *13 210 10 930 *4590 *4590 12.95
25.0 ft lb *31,850 *31,850 *28,750 23,150 *10,150 *10,150 42.33
6.0 m kg *23 670 *23 670 *18 860 *18 860 *15 860 15 000 *13 820 10 740 *4630 *4630 13.37
20.0 ft lb *50,800 *50,800 *40,650 *40,650 *34,300 32,100 *29,950 22,850 *10,200 *10,200 43.80
4.5 m kg *27 490 *27 490 *21 020 19 860 *17 150 14 230 *14 560 10 360 *11 900 7400 *4800 *4800 13.58
15.0 ft lb *59,050 *59,050 *45,300 42,750 *37,050 30,500 *31,500 22,050 *19,800 15,600 *10,550 *10,550 44.53
3.0 m kg *30 490 26 220 *22 900 18 420 *18 330 13 420 *15 260 9910 12 670 7230 *5110 5000 13.58
10.0 ft lb *65,650 56,600 *49,400 39,650 *39,600 28,800 *32,950 21,150 *26,000 15,250 *11,250 11,050 44.57
1.5 m kg *27,420 24 450 *24 110 17 280 *19 160 12 710 *15 720 9500 12 470 7050 *5580 5090 13.39
5.0 ft lb *66,850 52,650 *52,050 37,150 *41,350 27,250 *33,950 20,300 *26,250 14,900 *12,300 11,210 43.93
Ground kg *29 590 23 670 *24 440 16 560 *19 440 12 210 *15 790 9190 *6260 5460 12.98
Line lb *68,550 50,850 *52,850 35,600 *42,000 26,200 33,900 19,650 *13,800 12,050 42.58
–1.5 m kg *17 180 *17 180 *30 270 23 530 *23 840 16 260 *19 030 11 960 *15 220 9050 *7240 6210 12.34
–5.0 ft lb *39,550 *39,550 *65,650 50,500 *51,550 34,900 *41,050 25,650 *32,600 19,350 *16,000 13,750 40.44
–3.0 m kg *18 410 *18 410 *27 750 *27 750 *27 820 23 840 *22 220 16 320 *17 680 11 980 *13 530 9140 *8690 7550 11.42
–10.0 ft lb *41,700 *41,700 *63,550 *63,550 *60,250 51,150 *47,950 35,050 *37,950 25,700 *28,450 19,650 *19,200 16,800 37.36
–4.5 m kg *29 110 *29 110 *29 260 *29 260 *24 030 *24 030 *19 280 16 720 *14 860 12 310
–15.0 ft lb *66,000 *66,000 *63,300 *63,300 *51,800 *51,800 *41,300 35,950 *31,350 26,500
–6.0 m kg *21 820 *21 820 *18 220 *18 220 *14 090 *14 090
–20.0 ft lb *46,500 *46,500 *38,600 *38,600 *29,200 *29,200
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤ ➤ ➤
➤
➤
➤
➤ ➤ ➤ ➤ ➤
➤
➤
➤
BOOM – 8.4 m (27'7")
STICK – 3400 mm (11'2") BUCKET – 2260 mm (89") GP with HD long tips
SHOES – 900 mm (36") double grouser UNDERCARRIAGE – Long
HEAVY LIFT – On
